Brackish water desalination is the procedure of reverse osmosis separating the excess of dissolved salts from brackish water, or any aqueous salt solution in order to collect low-salt content water for any suitable use, such as drinking, industrial, pharmaceutical, municipal, or household water.

As freshwater continues to recede to inaccessible parts of the aquifers, especially in the world’s most vulnerable or water-stressed regions, research efforts constantly seek new ways to efficiently and cost-effectively provide potable water from desalination. Until recently, brackish water desalination has been confined to the desert environment, where surface and groundwater resources are scarce. However, climate change challenges and other anthropogenic activities have systematically forced most near-shore or coaster communities to resort to brackish water desalination as a means of assessing drinking water. Great advancements in energy recovery equipment and membrane technology in the last two decades have created two-fold reduction in energy required to desalinate brackish water.

Our supplier manufactures desalination systems for different applications according to customer needs, with simple operation and easy maintenance. Effectively eliminating or reducing the salt concentration in brackish water, providing a stable and continuous supply of healthy and potable water.

Our products are commonly used in communities or remote areas for daily drinking water access, boat water desalination, food and beverage processing plants, oil and gas industry, boiler water supply, agricultural irrigation, emergency response services, etc. Below are our different models of desalination equipment.

1.5 TPD Brackish Water Desalination Machine

• Fresh Water Output: 1.5 tons per day
• System recovery rate: 12%
• Power Consumption:1.5KW
• Voltage: single-phase 220V/50HZ ，three-phase 380V/50HZ， three-phase 440V/50HZ（Customized）
• Working pressure: 35~55MPA
• Operating temperature: 5~45C
• Inlet water TDS: less than 40000PPM
• Desalination rate:99.2%
• TDS: less than 700PPM
• Inlet PH value: 3~10
• Size: 800mm*500mm*500mm
• Net weight: 100KG
• Packing net weight:120KG

3TPD Brackish Water Desalination Equipment

• Main features: small size, easy installation, convenient operation, and maintenance.
• Fresh Water Output: 3 tons per day
• Size: L*B*H=500mm*570mm*1350mm
• Weight: ≈150kg (dry weight)
• Power Consumption: 1.5kw
• System recovery rate: ≈15%(depending on temperature and water quality)
• Power supply: AC380V /50Hz/Customizable
• Electric control protection grade: IP56
• Product color: primary color
• Material composition: SUS316 stainless steel
• Effluent water quality: in accordance with GB5749-2006drinking water quality standard

5TPD Brackish Water Desalination Machine

• Main features: compact structure, generous;
• Easy to operate and maintain.
• Fresh Water Output: 5 tons per day
• Size: L*B*H=910mm*500mm*1540mm
• Weight: *260Kg (dry weight)
• Power Consumption: 22 KW
• System recovery rate: 20%(depending on temperature and water quality)
• Power supply:AC380V /50 Hz/Customizable
• Quality standard: comply with ship CCS inspection and provide the corresponding certificate
• Effluent quality: meet GB5749-2006 drinking water quality standards
  Electric protection grade: IP56
• Main components: high-pressure pump imported from Italy original 316L stainless steel material;
• The reverse osmosis membrane is made by the Dow brand.
• Effectively ensure the core quality of products.

10 TPD Brackish Water Machine

• Fresh Water Output: 10 tons per day
• Size: L*B*H=1520mm*800mm*1920mm
• Weight: ≈800Kg (dry weight)
• Power Consumption: 5.5 KWSystem recovery rate: 33%(depending on temperature and water quality)
• Power supply: AC380V /50 Hz/Customizable
• Effluent water quality: in accordance with GB5749-2006standard for drinking water quality
• Electric protection class: IP56
• Main components: high-pressure pump is imported from Italy AR brand,316L material
• The reverse osmosis membrane is made by Dow

25TPD Brackish Water Desalination System

• Fresh Water Output: 25 tons per day
• System recovery rate: 25%
• Power Consumption: 5.5KW
• Voltage: 440 V /60 HZ
• Working pressure: 3.5~5.5MPA
• Operating temperature:5~45℃
• Inlet TDS: less than 40000PPM
• Desalination rate: 99.2%
• TDS: less than 700PP
• MPH value of inlet water: 3~10
• Size: 1700mm*1120mm*1900mm
• Packing specification(wooden case): 1900*1320*2100mm
• Net weight of equipment: 800KG
• Packing net weight: 880KG

60 TPD Brackish Water Desalination Plant

• Fresh Water Output: 60 tons per day
• Size: L* B*H = 2250mm*1250mm*2040mm
• Weight: * 2500kg (dry weight)
• Power Consumption:18.5kw
• System recovery rate: 33%(depending on temperature and water quality)
  Power supply: AC380V / 50Hz, AC 440v /60Hz，AC480v /60Hz（Customized）
• Effluent water quality: in line with GB5749-2006 drinking water quality standard
• Electric control protection grade: IP56
• Main components: the high-pressure pump is made of sepck brand imported from Germany; the reverse osmosis membrane is made of American ceramic Brand.
